Automatic Cold Pressed Machine for Diamond Segment
- Name:Fully automatic mechanical cold press machine
- Model:BWM-KH35T/BWM-KH60T
- Maximum working pressure:35T / 60T
- Maximum volume of hopper box:30 kg
- Weight accuracy of piece:±2%
- Quantity of piece per time:1-4 PCS
- Work efficiency:21-25 Times/Min
- Device dimension:L850 * W1150 * H1800
- Place of origin:China
3. Strengthen wear parts optimization, maintenance rate is much lower than the past similar equipment,increasing service life of the machine;
4. Small and delicate LED work light;
5. Feeding the metal powder in the way of pneumatic, feeding more twice extraly in a short distance and more accurate;
6. This equipment has a pressure relief device, turning a hand wheel can relieve pressure easily when the machine is stuck;
7. It also can be used for press ceramic powder and metal powder etc.
Other specifications can be customized according to requirements.
Parameter |
||
Maximum working pressure |
35000 Kg |
60000KG |
Maximum size of mould cavity |
40*70 MM |
50*70MM |
Size of the mould |
L (220-250) * W 130 * H (20-30) MM |
L(220-250)*W(130-150)*H(20-40) MM |
The largest volume of hopper box |
30 Kg |
30 KG |
Maximum height of metal powder |
0.5-20 MM |
0.5-30 MM |
Weight accuracy of metal piece |
±2% |
±2% |
Quantity of metal piece per time |
1 - 4 PCS |
1-4 PCS |
Motor Power |
2.2 KW |
4 KW |
The rated voltage |
380 V |
380 V |
The rated current |
6 A |
10 A |
Work efficiency |
25 Times/Min |
21 Times/Min |
Distance of upward |
64 MM |
80 MM |
Device dimension |
L810 * W1000 * H1600 |
L850 * W1150 * H1800 |
Net weight |
760 Kg |
1000 KG |
If you do not find the product you want,please contact us for more product images.
![automatic mechanical cold press machine for segment](/uploads/upfile/601/images/6f/20161013194238930.jpg)
![automatic mechanical cold press machine for segment](/uploads/upfile/601/images/57/20161013194304251.jpg)
![automatic mechanical cold press machine for segment](/uploads/upfile/601/images/a6/20161013194315451.jpg)
![automatic mechanical cold press machine for segment](/uploads/upfile/601/images/4e/20161013194328690.jpg)
![automatic mechanical cold press machine for segment](/uploads/upfile/601/images/0b/20161013194340720.jpg)
![automatic mechanical cold press machine for segment](/uploads/upfile/601/images/89/20161013194350061.jpg)
We can also pack the products according to your requirements.
Special specifications need to be negotiated for delivery times.
![automatic mechanical cold press machine for segment](/uploads/upfile/601/images/67/20161013194412918.jpg)
