Boreway diamond segmented crack chaser blades
- Model Number: BW-DSCCB-001
- Type: Wet Use
- Diameter: 105mm to 229mm
- Segment Width: 6.4mm
- Segment Height: 8mm
- Segment number: 8 to 18
- Machine: Large cutting machine and cutting bridge machine.
- Industry: Diamond cutting tools
- Technology: Sintered
- Advantage: Good sharpness and long lifespan.
- Applications: Boreway diamond segmented crack chaser blades is wet use for cutting concrete brick block and masonry ect.
Introduction:
These diamond segmented crack chaser blades are mainly used for making grooves on the
surface of green concrete,masonry,joints of brick or block and other construction materials,
and repairing grout,cleaning and routing cement mortar joints.
Features:
1.Universal wet cutting crack chaser blades.
2.Higher diamond concentration than standard grade for fast cutting and long service life.
3.V-shaped segments suitable for working on cleaning,routing and repairing cement mortar joint.
Specifications:
The followings are the normal specifications of our diamond segmented crack chaser blades:
|
Product Name |
Outer Diameter |
Segment Width |
Arbor |
Segment Height |
Segment Number |
Applications |
||
|
Diamond Segmented Crack Chaser Blade |
inch |
mm |
inch |
mm |
mm |
mm |
pcs |
Concrete Brick Ceramic Masonry |
|
4’’ |
105 |
0.250’’ |
6.4 |
16/20 22.23 25.4/50 |
8 |
8 |
||
|
4.5’’ |
115 |
0.250’’ |
6.4 |
8 |
8 |
|||
|
5’’ |
127 |
0.250’’ |
6.4 |
8 |
10 |
|||
|
6’’ |
152 |
0.250’’ |
6.4 |
8 |
12 |
|||
|
7’’ |
178 |
0.250’’ |
6.4 |
8 |
14 |
|||
|
8’’ |
203 |
0.250’’ |
6.4 |
8 |
16 |
|||
|
9’’ |
229 |
0.250’’ |
6.4 |
8 |
18 |
|||
The above specifications are for reference, other specifications can be ordered by customers.
