Diamond gang saw blades
- Name: Diamond gang saw blades
- Model: BW-GSB
- Size: 3950-4600mm
- Blade length: 3950-4600mm
- Blade height: 180mm
- Blade thickness: 1.5-2.5mm
- Segment length: 20-50mm
- Segment width: Can be customized
- Applicable:Stone
| Product Description: |
Brief introduction:
Diamond gang saw blades are one of the most widely and most advanced tools used in cutting stone blocks.The diamond gang saw blades have the characteristics of high processing efficiency, high yield, high cutting accuracy, good surface evenness, high flexibility of plate size, saving water and electricity.
Features:
1.Using ultra high quality diamond powder, after coating titanium, reduce the heat damage.
2.High quality blank ensures smooth and efficient cutting.
3.Ultra vacuum hot pressing sintering technology to ensure the consistency and stability of products.
4.The sandwich structure is more stable in cutting and ensures the thickness, consistency and integrity of the plates.
All of our products have been strictly tested before access to market.
| Specification: |
Specification of diamond gang saw blades:
| Steel blank | Overall length (mm) |
3950 4100 4400 4600 |
| Blade height (mm) |
180 | |
| Blade thickness (mm) |
1.5 1.75 2.0 2.5 |
|
| Segment dimension | Length (mm) |
20-50 |
| Width (mm) |
2.4-2.2 2.8-2.4 3.5-2.9 4.2-3.6 |
Reference data:
| Materials | Cutting areas | Cutting speed |
| Beige stone series | 4000 ㎡ | 14-20 cm/h |
| Emperador stone series | 20000 ㎡ | 12-18 cm/h |
| Serpenggiante series | 45000 ㎡ | 16-18 cm/h |
| Sandstone series | 8000 ㎡ | 45-80 cm/h |
| Artificial stone series | 100000 ㎡ | 25-35 cm/h |
Other specification can be customized according to need.(Wholesale Diamond Gang Saw Blade For Stone Cutting)
| Images: |
Only parts of diamond gang saw blades,If you want know more details, please contact us
| Packing & delivery |
1.Tools packing in carton cases;
2.Large machines packing in wooden cases;
3.When tools are in large quantities, they are packing in wooden cases.
2.Large machines packing in wooden cases;
3.When tools are in large quantities, they are packing in wooden cases.
