Three-side edging machine for diamond saw blade-EM02
- Model Number: BW-EM-02
- Wheel diameter: 200mm
- Edging diameter: 250mm to 600mm
- Power : 4KW
- Dimension: 1400mm*800mm*1200mm
- Applications: The boreway BWM-EM02 three-side edging machine for diamond saw blade is designed for edging the diamond segments of diamond saw blades, making the blade can be used directly after leaving the factory.
- Industry: Boreway machine
- Result: Making the blade can be used directly after leaving the factory
- Advantage: High speed and Long lifespan.
Introduction:
The BWM-EM02 three-side edging machine for diamond saw blade is designed for edging the diamond segments of diamond saw blades, making the blade can be used directly after leaving the factory.
Features:
1. Bag type dust collector, dust-free operation is very environmentally friendly.
2. The blade automatic alignment system, to effectively address the oxide layer welding clear edge.
3. Speed, high efficiency, the appearance of the blade meet export standards.
4. User-friendly design, high degree of automation, to minimize operator labor intensity.
5. High efficiency, daily output 300-400 pieces.
Specifications:
The followings are the normal specifications of our three-side edging machine for diamond saw blade:
|
Parameters |
Numerical |
|
Type |
BWM-EM02 |
|
Wheel diameter |
ø200mm |
|
Edging diameter |
Ø250mm - Ø600mm |
|
Power |
4 KW |
|
Dimension |
1400mm*800mm*1200mm |
|
Power supply |
380V,50HZ |
|
Daily output |
300-400 pcs/day |
|
Weight |
360 Kg |
The above specifications are for reference, other or special specifications can be ordered by customers.
